Description | Specification |
Ethernet WAN | 1 RJ-45 SFP Gigabit combination port |
Ethernet LAN | 8 RJ-45 Gigabit Ethernet ports RV260P has 4 PoE ports with a 60W power budget |
Console port | 1 RJ-45 port |
WLAN | 3x3 802.11ac Wave 2 |
Network protocols | 1. Dynamic Host Configuration Protocol (DHCP) server 2. Point-to-Point Protocol over Ethernet (PPPoE) 3. Point-to-Point Tunneling Protocol (PPTP) Layer 2 Tunneling Protocol (L2TP) 4. DNS proxy 5. DHCP relay agent 6. Internet Group Management Protocol (IGMP) proxy and multicast forwarding 7. Rapid Spanning Tree Protocol (RSTP) 8. Dynamic DNS (DynDNS, No-IP, ChangeIP) 9. Network Address Translation (NAT), Port Address Translation (PAT) 10. One-to-one NAT 11. Port management 12. Port mirroring 13. Software-configurable DMZ to any LAN IP address Session Initiation Protocol (SIP) Application Layer Gateways (ALG) |
QoS | 1. 802.1p port-based priority on LAN port, application-based priority on WAN port 2. 4 queues 3. Differentiated Services Code Point (DSCP) support 4. Class of Service (CoS) 5. Bandwidth management for service prioritization |
NAT throughput | 800+ Mbps |
Concurrent sessions | 25,000 |
IPsec VPN throughput | 75+ Mbps |
