Cisco ISR4331-VSEC/K9

Item No.: ISR4331-VSEC/K9
Cisco 4331 Integrated Services Router delivers 100 Mbps to 300 Mbps aggregate throughput and offers one Enhanced service-module (SM-X) slot, which supports for both single- and double-wide service modules provides flexibility in deployment options. ISR433
INQUIRY
Description

Cisco  ISR4331-VSEC/K9





Product Overview

The Cisco 4000 Series Integrated Services Routers provide routing, hosting, security, and switching--all in a single, trustworthy platform. Build your digital branch to be secure, fast, and scalable. Quickly adopt the latest technologies, from SD-WAN to edge computing, while meeting the explosive network-performance needs driven by cloud applications and digital transformation.



Product Highlights

The Cisco 4000 family Integrated Services Router (ISR) revolutionizes WAN communications in the enterprise branch. With amazing levels of built-in intelligent network capabilities and convergence, it specifically addresses the growing need for application-aware networking in distributed enterprise sites. These locations tend to have lean IT resources. But they often also have a growing need for direct communication with both private data centers and public clouds across diverse links, including Multiprotocol Label Switching (MPLS) VPNs and the Internet. The Cisco 4000 series ISRs consolidate many must-have IT functions, including network, compute, and storage resources. The high-performance, integrated routers run multiple concurrent IWAN services without slowing your data throughput.
●      Predictable performance:Get a high-availability architecture designed for mission-critical branches. The ISR 4000 delivers high-speed, predictable performance and modularity to connect from most remote locations.
●      Network services:Deploy key integrated network services for your branch in minutes, virtually or on-premises, without sacrificing performance.
●      Simplified management:Configure and monitor your network and enforce business policies through Cisco DNA Center and Cisco SD-WAN. Simplify network automation and turn hours of work into minutes.
●      Threat protection:Protect your branch site across the LAN and WAN and in the cloud with security integrated into the router. You no longer need a separate security appliance.


Product  Specifications Datasheet )

   Product Code

ISR4331-VSEC/K9

   Device Type

Router

   Enclosure Type

Rack-mountable - modular - 1U

   Connectivity Technology

Wired

   Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

   Performance

Aggregate throughput: 100 Mbps

   Network / Transport Protocol

IPSec, PPPoE, DHCP

   Routing Protocol

OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), IPv4-to-IPv6 Multicast

   Remote Management Protocol

SNMP, RMON

   Features

 Firewall protection, VPN support, VLAN support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), wall mountable, IPSec Virtual Private Network (VPN), Access Control List (ACL) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN), RADIUS support, NetFlow, IPFIX

   Compliant Standards

IEEE 802.3, IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824, CISPR 22 Class A, CISPR 24, EN55024, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 3548 Class A, GB 4943, VCCI V-3, EN 61000, KN22, KN24, CNS 13438, EN 55022 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1

   RAM

4 GB (installed) / 16 GB (max) - DDR3 SDRAM

   Flash Memory

4 GB (installed) / 16 GB (max)

Expansion / Connectivity

   Interfaces

WAN / LAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 | Serial: 1 x console - RJ-45 | Management: 1 x console - mini-USB Type B | Serial: 1 x auxiliary - RJ-45 | USB 2.0: 1 x 4 pin USB Type A | 2 x SFP (mini-GBIC) | Management: 1 x RJ-45

   Expansion Slots

2 (total) / 2 (free) x NIM | 1 (total) / 0 (free) x ISC | 1 (total) / 1 (free) x Enhanced Service Module (SM-X) | 2 (total) / 0 (free) x DIMM 240-pin

Power

   Power Device

Internal power supply - 250 Watt

   Installed Qty

1 (installed) / 1 (max)

   Voltage Required

AC 120/230 V (50/60 Hz)

Miscellaneous

   Included Accessories

32-channel voice DSP module

   Rack Mounting Kit

Included

Software / System Requirements

   OS Provided

Cisco IOS Security

   Software Included

Cisco IOS IP Base, Cisco IOS Unified Communications, Cisco Unified Border Element Enterprise Edition (10 sessions)

Dimensions & Weight

   Dimensions  Width*Depth*Height

17.2 *17.2*1.8 in

   Weight

11.02 lbs
